| Parameter | Unit | DY-SBF-PET-01 | DY-SBF-PET-02 | DY-SBF-PET-03 |
| Variant | Bronze conductive | Carbon conductive | Flat hydrolysis-resistant warp | |
| Material | Polyester monofilament or mixed-yarn fabric, as listed | Polyester monofilament or mixed-yarn fabric, as listed | Polyester monofilament or mixed-yarn fabric, as listed | |
| Warp filament | mm | 0.68 PET + 0.45 bronze | 0.68 PET + 0.45 carbon | 0.55 × 0.38 |
| Weft filament | mm | 0.80 PET | 0.80 PET | 0.60 PET |
| Warp density | threads/cm | 12 | 12.3 | 20.5 |
| Weft density | threads/cm | 6.8 | 6.3 | 10.5 |
| Air permeability | m³/(m²·h) | 9887 | 8500 | 9600 |
| Ordering details | ||||
| Joint | WP – Woven pin seam | WP – Woven pin seam | WP – Woven pin seam | |
| Edge finish | PU – Polyurethane edge seal | PU – Polyurethane edge seal | PU – Polyurethane edge seal | |
| Color | N – Natural / white | N – Natural / white | N – Natural / white | |
| Order dimensions (example) | mm | W3200-L18000 | W3200-L18000 | W3200-L18000 |
| Order code (example) | DY-SBF-PET-01/W3200-L18000/WP/PU/N/R01 | DY-SBF-PET-02/W3200-L18000/WP/PU/N/R01 | DY-SBF-PET-03/W3200-L18000/WP/PU/N/R01 | |
| Dimensions | Custom finished dimensions to the machine drawing. | |||
| Specification scope | Nominal fabric specifications; assembly details apply as listed. | |||
No. Fiber, airflow, speed, web weight and machine geometry must be matched.
No. Resistance paths, seams, contacts and machine grounding must be verified.
