| Parameter | Unit | DY-RDF-PET-01 | DY-RDF-PET-02 |
| Variant | Balanced retention | High drainage | |
| Material | Polyester monofilament or mixed-yarn fabric, as listed | Polyester monofilament or mixed-yarn fabric, as listed | |
| Warp filament | mm | 0.50 × 0.32 | 0.50 × 0.32 |
| Weft filament | mm | 600D + 0.50 | 6 × 0.18 + 0.50 |
| Warp density | threads/cm | 28.5 | 28.5 |
| Weft density | threads/cm | 21 | 25 |
| Fabric caliper | mm | 1.9 | 1.95 |
| Fabric mass | g/m² | 900 | 1200 |
| Air permeability | m³/(m²·h) | 720 | 1600 |
| Nominal filtration class | µm | 20–50 | 50–80 |
| MD breaking strength | N/cm | 2200 | 2200 |
| Joint breaking strength | N/cm | 1000 | 1000 |
| Ordering details | |||
| Joint | MC – 316L flat clipper with cover flap | MC – 316L flat clipper with cover flap | |
| Edge finish | PU – Polyurethane edge seal | PU – Polyurethane edge seal | |
| Color | N – Natural / white | N – Natural / white | |
| Order dimensions (example) | mm | W2000-L12000 | W2000-L12000 |
| Order code (example) | DY-RDF-PET-01/W2000-L12000/MC/PU/N/R01 | DY-RDF-PET-02/W2000-L12000/MC/PU/N/R01 | |
| Dimensions | Custom finished dimensions to the machine drawing. | ||
| Specification scope | Nominal fabric specifications; assembly details apply as listed. | ||
Only after checking differential pressure, support, sealing and closure design for that machine.
No. Some machines use fixed panels or covers; belt-discharge machines use moving belts.
Fabric surface, cake properties, thickness and the discharge mechanism act together.
Send particle distribution, target filtrate quality, fluid chemistry, temperature, equipment and support details, sample requirements and finished format.
