| Parameter | Unit | DY-PPF-PAPET-01 | DY-PPF-PAPET-02 | DY-PPF-PAPET-03 | DY-PPF-PAPET-04 | DY-PPF-PAPET-05 |
| Variant | Single-layer tissue felt | Double-layer press felt | Triple-layer press felt | Multi-axial laminated felt | On-machine seamed felt | |
| Material | Polyamide batt / textile base construction | Polyamide batt / textile base construction | Polyamide batt / textile base construction | Polyamide batt / textile base construction | Polyamide batt / textile base construction | |
| Base layers | count | 1 | 2 | 3 | 1+1 | 2 |
| Fabric mass | g/m² | 700–800 | 1100–1400 | 1500–1700 | 1000–1350 | 800–1600 |
| MD breaking strength | N/5 cm | ≥2000 | ≥3000 | ≥4500 | ≥3500 | ≥2500 |
| Structure | type | Needled PA batt on woven base | Needled PA batt on woven base | Needled PA batt on woven base | Needled PA batt on woven base | Needled PA batt on woven base |
| Ordering details | ||||||
| Joint | EN – Endless supplied configuration | EN – Endless supplied configuration | EN – Endless supplied configuration | EN – Endless supplied configuration | WP – Woven pin seam | |
| Edge finish | SE – Sewn reinforced edge | SE – Sewn reinforced edge | SE – Sewn reinforced edge | SE – Sewn reinforced edge | SE – Sewn reinforced edge | |
| Color | N – Natural / white | N – Natural / white | N – Natural / white | N – Natural / white | N – Natural / white | |
| Order dimensions (example) | mm | W3000-L20000 | W3000-L20000 | W3000-L20000 | W3000-L20000 | W3000-L20000 |
| Order code (example) | DY-PPF-PAPET-01/W3000-L20000/EN/SE/N/R01 | DY-PPF-PAPET-02/W3000-L20000/EN/SE/N/R01 | DY-PPF-PAPET-03/W3000-L20000/EN/SE/N/R01 | DY-PPF-PAPET-04/W3000-L20000/EN/SE/N/R01 | DY-PPF-PAPET-05/W3000-L20000/WP/SE/N/R01 | |
| Dimensions | Custom finished dimensions to the machine drawing. | |||||
| Specification scope | Nominal fabric specifications; assembly details apply as listed. | |||||
No. Felts combine a base and fiber batt and may use different polymers and manufacturing processes.
Only after position and grade qualification, including seam-marking and mechanical checks.
We combine precision weaving technology, premium raw materials, fast support, and true customization. Plus, our products serve over 80 countries worldwide.
