| Parameter | Unit | DY-FF2-PET-01 | DY-FF2-PET-02 |
| Variant | Balanced drainage | Fine sheet support | |
| Material | Polyester monofilament or mixed-yarn fabric, as listed | Polyester monofilament or mixed-yarn fabric, as listed | |
| Warp filament | mm | 0.17 | 0.17 |
| Warp density | threads/cm | 60 | 65.7 |
| Weft density | threads/cm | 48 | 49.6 |
| Fabric caliper | mm | 0.635 | 0.635 |
| MD breaking strength | N/cm | 800 | 800 |
| Air permeability | m³/(m²·h) | 5200 | 4550 |
| Weft yarn pair | mm | 0.17 / 0.2 | 0.17 / 0.22 |
| Ordering details | |||
| Joint | EN – Endless supplied configuration | EN – Endless supplied configuration | |
| Edge finish | TS – Thermally sealed edge | TS – Thermally sealed edge | |
| Color | N – Natural / white | N – Natural / white | |
| Order dimensions (example) | mm | W3000-L25000 | W3000-L25000 |
| Order code (example) | DY-FF2-PET-01/W3000-L25000/EN/TS/N/R01 | DY-FF2-PET-02/W3000-L25000/EN/TS/N/R01 | |
| Dimensions | Custom finished dimensions to the machine drawing. | ||
| Specification scope | Nominal fabric specifications; assembly details apply as listed. | ||
No. This refers to a documented multilayer woven structure, not an arbitrary stack.
Yes. Their material, dimensions and roles help explain support, wear and drainage.
Send former layout, dimensions, speed and tension, furnish, grades, drainage-element data, current fabric construction and the principal quality or wear issue.
